Engine Management

Chief Engines Electronic Engine Management System
screen-of-fuel-map1sm

Completely water proof with surface mounted potted circuitsfuelmap1

Harnesses contain mil-spec wire, NTFR and mil-spec connectors

Real time 3D mapping

Up to 24 injectors sequential with individual cylinder trim

8 coil fully sequential with individual cylinder trim

(Distributor less, coil per cylinder, single coil or wasted spark)

No external ignition amplifier needed

Individual cylinder trims with fuel and ignition

Crank and cam sensor with LED lights

Multiple IAC motor control

Electronic Boost by-pass control for supercharged engines

Independent 3D wastegate control for turbo charge engines

Anti-lag strategies

Soft and hard rev limiter strategies

Fast start strategies

Fuel and ignition multipliers

ignmap

Numerous Sensor configurations

“Limp home” modes

Internal power supply control

Close loop lambda control

Fly-by-wire control

Transmission control

6 PWM ovutput

Knock control

Fuel pump control

Ethernet connection

Thermocouple outputs

Dash Board Monitoringdashmonomega-024

Displays real time operating statistic of engines: tachometer, water temp, oil temp, air temp, water psi, oil psi, boost psi,

fuel psi, intercooler water psi, volts, fuel consumption, sync, tps, fuel pump, A/F ratio

Displays real time operating alarms: knock, hot water temp, hot oil temp, hot air temp, low water psi, low oil psi, low fuel

psi,, low voltage, low intercooler water psi

Discplays ECU sensor alarms: crank sensor, cam sensor, tps sensor, ect sensor, ait sensor, eot sensor, oil psi sensor, water

psi sensor, fuel psi sensor, injector failure, map sensor, ecu error

Sunlight readable and waterproof

In alarm mode; display turns red and displays alarm

Data Logging data logging
datalogging
17 hours of engine data and 250+ channels available speed, tach, eot, eop, iat, map, wt, fp, iac, crank, cam, lambda, ign, fuel, tps, anolog pressure sensors, ft, voltage, digital sensors, knock, thermocouple, run time, fuel consumption, steering angle trim and tab indicator, drive temp, fuel level, water level, G-meter, sensor condition

Videovideo demo

4 camera recording at 520 resolution synchronized to engine data Recorded on CF card
Real time view thru telemetry
Error code self diagnostics
vidsii-demo
Telemetry
Real time ecu control
Uploads, down loading and viewing

System 1
Marine ECU, sequential inj, fly lead wire harness, ect, iat, map, iac, tps, sensors, distributor, software, 8 injectors

System 2
Marine ECU, fully configured maps and software for CE ELECTRONIC ENGINE MANAGEMENT SYSTEM, ready to start, fully sequential, alpha-n or speed density, 3mg data logging, wire harness, ect, iat, map, iac, tps, sensors, distributor, 8 injectors, coil, configured laptop

System 3
Marine waterproof MILSPEC ECU, fully configured maps and software for CE ELECTRONIC ENGINE MANAGEMENT SYSTEM, ready to start, fully sequential, alpha-n or speed density, 4mg data logging, wire harness, ect, iat, map, iac, tps, sensors, distributor, 8 injectors, coil, configured laptop.

System 4
Marine waterproof MIL SPEC ECU , fully configured maps and software for CE COMPETITION ELECTRONIC ENGINE MANAGEMENT SYSTEM, ready to start, fully sequential and banked inj, alpha-n or speed density, 4mg data logging, mil spec tft shrink wire harness, ect, iat, map, iac, tps, intercooler psi, oil psi, water psi, fuel psi, cam and crank sensors, multi pattern crank trigger, 8 wasted spark coils, dashboard, knock control, fuel pump control, up to 24 injectors (43#-160#), configured laptop.
